Heating magnetic stirrer 2.000 rpm / T 320°C

Analogue model with circular stainless steel plate

Economic magnetic stirrer with stainless steel heating plate.

  • Fixed safety circuit 400 °C
  • Soft-start stirring motor


Stirring quantity (H2O): 10 l
Speed range: 100 – 2.000 rpm
Heat output: 400 W
Temperature range: RT – 320 °C

Technical specifications

Code IK/0333/9000
Stirring quantity max. per stirring position (H2O) 10 l
Motor rating output 2 W
Speed control scale 0 - 6
Speed range 100 - 2000 rpm
Heat output 400 W
Heating temperature range room temp. - 320 °C
Heat control scale 1 - 6
Fixed safety circuit 400 °C
Set-up plate material stainless steel 1.4301
Set-up plate dimensions Ø 125 mm
Dimensions (W x H x D) 168 x 105 x 220 mm
Weight 2.4 kg
Permissible ambient temperature 5 - 40 °C
Permissible relative humidity 80 %
Protection class according to DIN EN 60529 IP 21
Voltage 220 - 240 / 115 / 100 V
Frequency 50/60 Hz
Power input 415 W
