Bottles "pressure plus+" plastic coated DR Series

Pressure resistance conforms to DIN EN 1595

Graduated bottles for high pressure/vacuum applications plastic coated.

The coating provides scratch, leak and splinter protection and is ideally suited to both the transport and storage of hazardous media or valuable samples.

With easy-to-read scale and large labelling field for easy marking, in fired-on, highly durable ceramic.

  • Pressure resistance conforms to DIN EN 1595, confirmed by GS marking (TÜV ID: 0000020716)
  • Vacuum and/or pressure resistant from – 1 bar to + 1.5 bar due to modified geometry (based on ISO 4796-1)
  • When pressure loaded the following apply: thermal shock resistance 30 K and maximum usage temperature + 140 °C
  • Blue scale for visual differentiation from the standard laboratory bottle
  • Typical applications: safe working under pressure or vacuum, sampling under pressure, storage of gas generating media

Technical specifications

Code Capacity
(ml)
DIN GL Ø
(mm)
h
(mm)
Qty
DR/218152402 100 45 56 100 10
DR/117592500 250 45 70 138 10
DR/117592600 500 45 86 176 10
DR/218155408 1.000 45 101 225 10

N.B. Foreign import product: if not immediately available in stock, estimated delivery time in 30 days
