"Research Grade" pH/mV Meter (0.001 pH)

Large color LCD, capacitive touch keys, and USB port for computer connectivity

HN/005221-02 - Laboratory Research Grade Benchtop pH/mV Meter with 0.001 pH Resolution

The HN/005221-02 is an advanced research grade benchtop pH/mV meter that is completely customizable with a large color LCD, capacitive touch keys, and USB port for computer connectivity.

The HN/005221-02 is rich in features including five-point calibration, selectable resolution, data logging, alarm limits, comprehensive GLP, and much more.

This meter retains simplicity with both dedicated keys for routine operation and virtual keys that guide the user through setup options.

The HN/005221-02 ensures confidence in measurements with the exclusive  CAL Check feature that alerts the user to potential problems during calibration including if the buffer is contaminated or the probe needs to be cleaned.

Save on calibration solutions when you bundle!

  • Large Color LCD
  • CAL Check™
  • Capacitive Touch Keypad

Details

The HN/005221-02 is an advanced research grade benchtop pH/mV meter that is completely customizable with a large color LCD, capacitive touch keys, and USB port for computer connectivity.

The HN/005221-02 features a universal BNC connection for use with the expansive line of pH and ORP electrodes that Hanna Instruments offers.

The meter is supplied with the HN/01131B glass body, double junction, combination pH electrode that operates over a wide temperature range from 0 to 100°C.

All readings are automatically compensated for temperature variations with the separate HN/007662-T temperature probe that is included.

The HN/005221-02 can be calibrated up to five points with a choice of eight preprogrammed buffers or five custom buffers.

The HN/005221-02 features Hanna’s exclusive CAL Check  to alert the user of potential problems during the pH calibration process such as “Electrode Dirty/Broken” and “Buffer Contaminated.”

The overall probe condition based on the offset and slope characteristic of the electrode is displayed as a percentage after calibration is complete.

The calibration data including date, time, buffers used, offset and slope can be accessed at any time along with the current measurement by selecting the Good Laboratory Practice (GLP) display option.

Three selectable logging modes are available: automatic, manual and AutoHold logging.

Up to 100,000 data points can be recorded in 100 lots with 50,000 records max/lot and exported to a computer for data review and storage.

CAL check

              CAL Check Feature

GLP

         Comprehensive GLP Data

Logging

               Real-Time Logging

Features at-a-glance

Highly Customizable User Interface

  • The user interface of the HN/005221-02 allows the user to show measurements in various modes: basic measurement with or without GLP information, real-time graphing, and logging data
  • Calibration stability criteria can be adjusted from fast, moderate, and accurate
  • Programmable alarm limits can be set to inside or outside allowable limits

Color Graphic LCD

  • The HN/005221-02 features a color graphic LCD with on-screen help, graphic, and custom color configurations
  • The display allows for real-time graphing and the use of virtual keys provide for an intuitive user interface

Capacitive Touch

  • The HN/005221-02 features sensitive capacitive touch buttons for accurate keystrokes when navigating menus and screens
  • There are four dedicated keys that are used for routine operations including calibration and switching measurement modes and four virtual keys that change based upon use
  • The capacitive touch technology ensures the buttons never get clogged with sample residue

Choice of Calibration

  • Automatic buffer recognition, semiautomatic, and direct manual entry pH calibration options are available for calibrating up to five points, from a selection of eight standard buffers and up to five custom buffers

GLP Data

  • HN/005221-02 includes a GLP Feature that allows users to view calibration data and calibration expiration information at the touch of a key
  • Calibration data include date, time, buffers /standards used for calibration and slope characteristics. The offset is also displayed for pH electrodes.

CAL Check

  • CAL Check alerts users to potential problems during the calibration of the pH electrode
  • Indicators include “Electrode Dirty/Broken,” “Buffer Contaminated,” electrode response time and the overall probe condition as a percentage that is based on the offset and slope characteristics

Data Logging

  • Three selectable logging modes are available on the HN/005221-02: automatic, manual, and AutoHold logging
  • Automatic and manual logs up to 100 lots with 50,000 records max/lot, with up to 100,000 total data points
  • Automatic logging features the option to save data according to sampling period and interval

Data Transfer

  • Data can be transferred to a PC with USB cable and HI92000 software (both sold separately)

Contextual Help

  • Contextual help is always available through a dedicated “HELP” key
  • Clear tutorial messages and directions are available on-screen to quickly and easily guide users through setup and calibration
  • The help information displayed is relative to the setting/option being viewed

pH Specifications

pH Range -2.0 to 20.0 pH, -2.00 to 20.00 pH, -2.000 to 20.000 pH
pH Resolution 0.1, 0.01, 0.001 pH
pH Accuracy (@25ºC/77ºF) ±0.1 pH, ±0.01 pH, ±0.002 pH ±1 LSD
pH Calibration automatic, up to five point calibration, eight standard buffers available (1.68, 3.00, 4.01, 6.86, 7.01, 9.18, 10.01,12.45) and five custom buffers
pH Temperature Compensation automatic or manual from -20.0 to 120.0 °C
mV Range ±2000 mV
mV Resolution 0.1 mV
mV Accuracy ±0.2 mV ±1 LSD
Relative mV Offset Range ±2000 mV

Temperature Specifications

Temperature Range -20.0 to 120.0 ºC, -4.0 to 248.0 °F, 253.15 to 393.15 K
Temperature Resolution 0.1 °C, 0.1 °F, 0.1 K
Temperature Accuracy ±0.2 °C, ±0.4 °F, ±0.2 K


Additional Specifications

Electrode/Probe HN/01131B glass body pH electrode with BNC connector and 1 m (3.3’) cable (included)
Temperature Probe HN/007662-T stainless steel temperature probe with 1 m (3.3’) cable (included)
GLP calibration data including date, time, buffers used, offset and slope
Logging record: 100,000 data point storage, 100 lots with 50,000 records/lot; interval: settable between 1 second and 180 minutes max log time; type: automatic, manual, AutoHold
Input Channels 1 - pH/ORP
Display color graphic LCD with on-screen help, graphing, and custom color configuration
Connectivity USB
Environment 0 to 50°C (32 to 122°F; 273 to 323 K), RH max 95% non-condensing
Power Supply 12 VDC adapter (included)
Dimensions 160 x 231 x 94 mm (6.3 x 9.1 x 3.7”)
Weight 1.2 kg (2.64 lbs.)
Ordering Information HN/005221 is supplied with HN/01131B pH electrode, HN/007662-T temperature probe, HN/76404W electrode holder, HN/070004 pH 4.01 buffer solution sachet, HN/070007 pH 7.01 buffer solution sachet, HN/0700601 electrode cleaning solution sachet (2), HN/007082 3.5M KCl electrolyte solution (30 mL), 12 VDC adapter and instructions.
